High Capacity Plastic Pipe Extrusion Machine HDPE Corrugated Pipe Equipment SGS

Name: High Capacity Plastic Pipe Extrusion Machine HDPE Corrugated Pipe Equipment SGS
Brand: wangyuan
Price: 27895 USD

Wholesale High Capacity Plastic Pipe Extrusion Machine HDPE Corrugated Pipe Equipment SGS from china suppliers

Brand Name : wangyuan

Model Number : Sj75/33 + Sj50/33 extruder

Certification : SGS

Place of Origin : China

MOQ : 1

Price : 27895-49777usd

Payment Terms : L/C T/T

Supply Ability : 5 set per month

Delivery Time : 50days

Packaging Details : film

pipe name : HDPE Double Wall Corrugated Cable Duct

pipe mould : 38 pairs .60pairs

pipe speed : 2-6m.min

pipe Application : Drainage Corrugated Tube Making Machine

Application : Frontage drains for terrace and other residential units in housing schemes

Application 2 : Pipe Manufacture Extruder Making Machine DWC Corrugated Pipe Making Machine

Contact Now

Plastic Pipe Extrusion Machine Hdpe Corrugated Tube Equipment Electrical Conduit Pipe Extruder

HDPE/PVC Double Wall Corrugated Pipe Making Machine

Double Wall Corrugated Pipe Production Line

HDPE double wall corrugated pipe making machine

dwc pipe manufacturing machine

corrugated pipe is mainly used for water drainage system. It is a fully computer controlled line. It features high and stable output capacity, and highly automatic operation. For HDPE, you can choose high efficient single screw extruder. For PVC, you can choose conical twin-screw extruder or parallel twin- screw extruder. Forming system consists mould and corrugator.
Mould blocks can be easily changed and they have air or water cooling system. The belling process is on line. High precision cutting can be guaranteed by cutting machine. The production line can also be equipped with SIEMENS PLC system.

Type Pipe	Diameter(mm)	HDPE Output(kg/h)	MAX Speed(m/min)
CS-160	50-160	300-400	5
CS-500	200-500	600-700	3
CS-800	200-800	1000-1100	3
CS-1200	600-1200	1000-1200	1

plastic single wall corrugated pipe machine

1. plastic single wall corrugated pipe machine can produce PP PE PA PVC EAV corrugated pipe which is widely used as wire harness protective pipe for car and machine tool

2. equip with vacuum pump, the machine can produce washing machine pipe, air conditioner pipe, hookah pipe, wash basin drain pipe,medical pipe

3.mold transmission by gear

4. water cooling, wind cooling

Main Technical Parameter---Single Wall Corrugated Pipe Make Machine:

Extruder Model	SJ45	SJ65
Screw diameter (mm)	45	65
Ration of L/D	28-33:1	28-33:1
Pipe diameter range	9-32	32-110
Pairs of modules	40	72
Line speed (m/min)	3-15	3-15
Module cooling way	Air-cooled	Air-cooled
Pipe cooling way	Air-cooled	Air-cooled
Total install powder (kw)	50	70

Main applications:
Building industry: electrical conduit & sanitary hose duct/flexible pipe for siphon, PP-PE-PVC-PA
Automotive industry: Fuel line pipe & wiring harness tubing, PP-PA6-PA11-PA12-PA612
Medical industry: breathing tubes, LLDPE,EVA
